Biostar TA790GX A3 PLUS User Manual

TA790GX A3+
29
V6 Tech Engine
This engine will make a good over-clock performance.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx. xx (C)Copyrig ht 1985-200x , American Mega trends, Inc.
Select Screen
Select Item
Change Option
General Help
Sav e and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause syste m to malfuncti on.
=========== Automate OverClock System ===========
============ Manual OverClock System ============
OverClock Navigator [Automate OverClock]
Aut o OverClock Sy stem [V6 -Tech Engine ]
CPU/HT Reference Clock (MHz) [200]
CPU Configuration [Auto]
ATIG Reference Clock (MHz) [100]
SB Re ference Cloc k (MHz) [100]
Spread Spectrum [Disabled]
> G.P.U Phase Control
> CPU FID/VID Control
> Voltage Configuation
> D RAM Timing Configurat ion
> Hyper Transport Configuration
Exit
Op tions
V6-Tech Engine
V8-Tech Engine
V12-Tech Engine
V8 Tech Engine
This engine will make a better over-clock performance.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx. xx (C)Copyrig ht 1985-200x , American Mega trends, Inc.
Select Screen
Select Item
Change Option
General Help
Sav e and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause syste m to malfuncti on.
=========== Automate OverClock System ===========
============ Manual OverClock System ============
OverClock Navigator [Automate OverClock]
Aut o OverClock Sy stem [V8 -Tech Engine ]
CPU/HT Reference Clock (MHz) [200]
CPU Configuration [Auto]
ATIG Reference Clock (MHz) [100]
SB Re ference Cloc k (MHz) [100]
Spread Spectrum [Disabled]
> G.P.U Phase Control
> CPU FID/VID Control
> Voltage Configuation
> D RAM Timing Configurat ion
> Hyper Transport Configuration
Exit
Op tions
V6-Tech Engine
V8-Tech Engine
V12-Tech Engine
V12 Tech Engine
This engine will make a best over-clock performance.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx. xx (C)Copyrig ht 1985-200x , American Mega trends, Inc.
Select Screen
Select Item
Change Option
General Help
Sav e and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause syste m to malfuncti on.
=========== Automate OverClock System ===========
============ Manual OverClock System ============
OverClock Navigator [Automate OverClock]
Auto OverClock System [V12-Tech Engine]
CPU/HT Reference Clock (MHz) [200]
CPU Configuration [Auto]
ATIG Reference Clock (MHz) [100]
SB Re ference Cloc k (MHz) [100]
Spread Spectrum [Disabled]
> G.P.U Phase Control
> CPU FID/VID Control
> Voltage Configuation
> D RAM Timing Configurat ion
> Hyper Transport Configuration
Exit
Op tions
V6-Tech Engine
V8-Tech Engine
V12-Tech Engine
