1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pent ium / C eleron
processor
Supports Execute Disable B it / Enhanced Intel
SpeedStep® / Intel Arch itecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyp er Thr ead ing
Chipset
Intel H61
Super I/O
IT8728
Provides the most commonly used leg acy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1066 / 1333 / 1600 (depending on
CPU)
Registered D IMM and ECC DIMM is not supported
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s
SATA Version 2.0 specif icat ion co mp liant
LAN
Realtek RTL8111E-VL-CG
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
VT1708B
5.1 channels audio out
High Definition Audio
PCI slot x2 Supports PCI expansion card
PCI-E Gen3 x16 @ x16 slot x1
(depend ing on CPU)
Supports PCI-E Gen2/3 x16 expansion card
PCI-E Gen2 x16 @ x1 slot x1 Supports PCI-E Gen2 x1 expansion card
Slots
PCI-E Gen2 x1 slot x2 Supports PCI-E Gen2 x1 expans ion card
SATA2 Connector x4 Each connector supports 1 SATA2 device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
On Board
Connectors
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
