TZ77XE3/TZ75XE3
21
Enable RAID / AHCI Driver when installing Windows 7/Vista
1. Before you start Windows installation, copy the proper files for the Windows
version to any USB storage.
Windows 7 32 Windows 7 64
Windows Vista 32 Windows Vista 64
SATA1/SATA2/
SATA3/SATA4/
SATA5/SATA6
AHCI/RAID
Driver Path
x:\Driver\Chipset\
Intel\SATA\7\F6flpy
32\Driver\
x:\Driver\Chipset\
Intel\SATA\7\F6flpy
64\Driver\
x:\Driver\Chipset\
Intel\SATA\7\F6flpy
32\Driver\
x:\Driver\Chipset\
Intel\SATA\7\F6flpy
64\Driver\
2. Follow Windows 7 / Vista indication to load the driver in the installation process.
4.2 R
AID ARRAYS
CONNECTOR BY CHIP SPEED Support
SATA1/SATA2 Intel Z77 / Z75 6 Gb/s. RAID 0 / 1 / 5 / 10
SATA3/SATA4/SATA5/SATA6 Intel Z77 / Z75 3 Gb/s. RAID 0 / 1 / 5 / 10
RAID supports the following types of RAID arrays:
RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write
times for many applications.
RAID 1: RAID 1 defines techniques for mirroring data.
RAID 10: RAID 10 combines the techniques used in RAID 0 and RAID 1.
RAID 5: RAID 5 provides fault tolerance and better utilization of disk capacity.
