Bird SiteHawk Operation Manual
7
Measurement Port
The measurement port is a 50 ohm N-type. This port is used to connect the
device under test.
User Interface
The SiteHawk user interface consists of a touch screen interface. The user
presses the screen to access menus, change settings, perform measurements
and save results.
Note: The displays used in this manual are shown with the Site-
Hawk in the horizontal position, some menus may display differ-
ently if accessed with the unit in a vertical position. Display options
can be controlled via the settings menu on the home screen.
