BIRD SiteHawk SK-4500 - Measurement Mode UI Details

Bird SiteHawk Operation Manual
9
Note: When a fault Detection mode is selected, the Start distance,
stop distance, and DTFMax fields are also displayed below the
sweep display area.
6 DTF icon, press to display the Distance to Fault
menu.
7 CAL icon, press to display the calibration menu.
8 Menu icon, press to display additional utility menus:
MEM, FREQ, RESET
, FILE, PNG, SYS.
9 Device information row, includes date, time,
longitude, latitude, battery time remaining, battery
percentage remaining.
10 Stop Frequency, press the data field to change the
value, or press the label to change to frequency Span
(14).
11 Sweep display area.
12 Points, press the data field to choose the number of
measurement points.
13 Start Frequency, press the data field to change the
value, or press the label to change to Center
Frequency (15).
14 Span displays the current frequency span. Press the
data field to change the value, or press the label to
change to Stop Frequency (9).
15 Center Frequency, press the data field to change the
value, or press the label to change to Start
Frequency (13).
