AEG WATERTIGHT MAGNETIC
SWITCH ASSEMBLY
NOTE
SERIAL NO.
REQUIRED
PUSH
TO
STOP
PU
T
STA
A16226A-SG
LW15S (2)
HN20S (2)
H462A
or
H462-2
297-1
241GR
16296-3
LW20S (2)
HHS070S (2)
LW03S (4)
HN05S (4)
241BL
224-1F
or
224-1N
241WH
224-1P
151
225-3
or
225-1P
226-28 (2)
226EE-22PB-RE
or
42MC-Y74
RHS075S (4)
226EE-22PB-GE
or
42MC-Y73
226EE or
SPECIFY
ELECTRICAL
SPECS
Description
A22616EE-514
BAEG/MS-PB/05-C8 2HP 208-220-50/60-3
BAEG/MS-PB/05-E4.7 2HP 440/460-3
A22616EE-518
BAEG/MS-PB/05-D4.7 1.5-2HP 380/415-50-3
A22616EE-522
BAEG/MS-PB/05-C14 3HP 220-230-50/60-3
A22616EE-5221
BAEG/MS-PB/05-CS14 1.5HP 208/230-50/60-1
A22616EE-5241
BAEG/MS-PB/A26 1.5-2HP 104/115-60-1
A22616EE-5261
BAEG/MS-PB/CS16 2HP 230-60-1
A22616EE-516
Description
A22616EE-530
BAEG/MS-PB/05-F3.2 2HP 550/575-3
BAEG/MS-PB/05-E6.3 3HP 440/460-60-3
A22616EE-536
BAEG/MS-PB/05-D8 3HP 380-60-3
A22616EE-538
BAEG/PC-PB/05-F4.7 3HP 550-60-3
A22616EE-540
BAEG/MS-PB/C18 5HP 220-60-3
A22616EE-544
BAEG/MS-PB/05-E8 5HP 440/460-60-3
A22616EE-546
BAEG/MS-PB/05-D14 5HP 380/415-50-3
A22616EE-534
A22616EE-548
BAEG/MS-PB/05-F8 5HP 550/575-60-3
Item No. Item No.
WATERTIGHT MAGNETIC SWITCH ASSEMBLIES
(AEG)
INCLUDES MOUNTING BRACKET AND WIRES
Description
A16226A-SG
Green/red switch button assembly
Guard for switch toggle
H462A
HHS070S
HN05S
Hex nut, 8-32 SS
HN20S
Hex nut, 5/16-18 SS
H462-2
LW03S
Lock washer, #8 SS
Lock washer, 5/16 SS
LW20S
Lock washer, ⅜” SS
RHS075S
Round head screw, 8-32 x ¾ SS
16296-3
Switch bracket, SS
151
Watertight conduit
224-1P
Conduit connector, WT, 180°
LW15S
224-1F
224-1N
226EE-ENCL-PB30
226EE-OL01.9G
Overload, B18K-G, 1.3-1.9A
226EE-OL4I
Overload, B18K-I, 2.5-4A
H281EE-51
Overload, B18K-K, 4-6.3A
Overload, B18K-L, 5.5-8.5A
226EE-OL12M
Overload, B18K-M, 8-12A
226EE-OL180
Overload, B18K-O,14.5-18A
226EE-OL26ON
Overload, B18K-ON, 21-26A
226EE-AO
Contactor, LS05.10-AO, 120V
226EE-CO
Contactor, LS05.10-CO, 208-230V
226EE-OL08.5L
226EE-DO
Contactor, LS05.10-DO, 380-415V
Description
226EE-EO
Contactor, LS05.10-EO 440-480V
Contactor, LS05.10-FO 550V
226EE-514
BAEG/MS-PB/05-C8 2HP 220-50/60-3
226EE-516
BAEG/MS-PB/05-E4.7 2HP 440-60-3
226EE-518
BAEG/MS-PB/05-D4.7 2HP 380-50-3
226EE-FO
BAEG/MS-PB/05-C14 3HP 230-50/60-3
226EE-5241
BAEG/MS-PB/A26 2HP 120-60-1
226EE-5261
BAEG/MS-PB/CS16 2HP 230-60-1
226EE-530
BAEG/MS-PB/05-F3.2 2HP 550-60-3
226EE-534
BAEG/MS-PB/05-E6.3 3HP 440-60-3
226EE-536
BAEG/MS-PB/05-D8 3HP 380-50-3
226EE-522
226EE-538
BAEG/PC-PB/05-F4.7 3HP 550-60-3
226EE-540
BAEG/MS-PB/C18 5HP 220-60-3
226EE-544
BAEG/MS-PB/05-E8 5HP 440-60-3
226EE-546
BAEG/MS-PB/D14 5HP 380-415-50-3
226EE-548
BAEG/MS-PB/05-F8 5HP 550-60-3
226-28
Washer, 1½ x 27/32 SS
Wire, black 12 GA., CSA & UL
241GR
Wire, green 12 GA., CSA & UL
241WH
Wire, white 12 GA., CSA & UL
297-1
Wire terminal eyelet for 12 GA. wire
42MC-Y73
Green start pushbutton assembly, 30mm
42MC-Y74
Red stop pushbutton assembly, 30mm
241BL
Hex head screw, ⅜ -16 x 1 SS
Item No.
Item No.
Guard assembly for switch toggle
Conduit ferrule for watertight connector
Conduit nut for watertight connector
Enclosure w/ pushbutton, 30mm holes
226EE-ENCL-PB22
Enclosure w/ pushbutton, 22mm holes
226EE-22PB-GE
226EE-22PB-RE
Green start pushbutton assembly, 22mm
Red stop pushbutton assembly, 22mm
226EE-AO11K
Contactor, LS11K.11S-AO, 120V
226EE-CO11K
Contactor, LS11K.11S-CO, 208-230V
226EE-OL06.3K
Overload, B05-K,4-6.3A
226EE-OL08L
Overload, B05-L, 5.5-8.5A
Overload, B05-NN, 10-14A
226EE-OL04.7JN
Overload, B05-JN, 3-4.7A
226EE-OL14NN
To Next Page
