Bison 4DW91-29D - Outline Drawing of 4 Dx22-50 D and 4 Dx22-60 D

17
2.5 Outline drawings of 4DX22-50D and 4DX22-60D
installation position of
oil pressure sensor NPT1/8
external diameter of fuel
inlet and return pipes
for fuel pump Φ10
fuel drainage plug screw M20×1.5
4×M12 depth 21
302 center of exhaust vent
front end surface
of engine block
rear end surface
of engine block
480 center of exhaust vent
232 center of fan
4×M12 depth 21
