Bissell CLEANVIEW 1330 SERIES - Quick Start Guide; Assembly Instructions

Quick Start Guide
www.BISSELL.com
3
*Product images may vary
Assembly
1. Slide handle onto machine base
2. Screw 2 screws into existing holes with Phillips-head
screwdriver
3. Insert hose wand clip into back of vacuum base and
twist clockwise
4. Line up tabs on the cuff of the hose with the notches
on back of vacuum, twist hose clockwise to lock into place
5. Slide other end of hose into hose wand base and place
hose over upper hose wrap on handle
6. Slide tools into place
A
B
F
G
H I J
C
E
D
CARTON CONTENTS
A. Vacuum Base
B. Handle
C. Hose
D. Crevice Tool*
E. Extension Wand
F. Upper Cord Wrap
G. Hose Wand Clip
H. TurboBrush(R) Tool
I. Screws (2)
J. Dusting Brush
*Note: Crevice tool is located inside Extension Wand
CARTON CONTENTS
A. Vacuum Base
B. Handle
C. Hose
D. Crevice To ol
E. Extension Wand
F. Upper Cord Wrap
G. Hose Wand Clip
H. Turbobrush
®
To ol
I. Screws (2)
J. Dusting Brush
A
B
H
J
CDE
I
F
G
