BITMAIN ANTMINER S19j User Manual

- 15 -
S19j Server Installation Guide
3. Configuring the Server
3. Configuring the Server
Setting up the Pool
To configure the server:
1. Click Settings marked below.
Note:
1. Fan speed percentage can be adjusted, but we recommend to keep the default setting. The server will
adjust the fan speed automatically if the fan speed percentage has yet been selected.
2. There are two working modes of S19j server: Normal mode and Sleep mode. The server enters the sleep
mode under the condition that the control board is powered while hashboards are not powered.
2. Set the options according to the following table:
Option
Description
Mining address
Enter the address of your desired pool.
The S19j servers can be set up with three mining pools, with decreasing priority
from the first pool (pool 1) to the third pool (pool 3). The pools with low priority
will only be used if all higher priority pools are offline.
Name
Your worker ID on the selected pool.
Password (optional)
The password for your selected worker.
3. Click Save after the configuration.

BITMAIN ANTMINER S19j Specifications

General

Hash Rate	90 TH/s
Noise Level	75 dB
Weight	13.2 kg
Network Connection	Ethernet
Algorithm	SHA-256
Efficiency	34.5 J/TH
Operating Temperature	0°C to 40°C
Voltage	220V - 240V
Power Consumption	3250 W
Dimensions	370 x 195.5 x 290 mm
Chip	BM1362
