BITMAIN ANTMINER S19j User Manual

- 16 -
S19j Server Installation Guide
4. Monitoring Your Server
4. Monitoring Your server
To check the operating status of your server:
1. Click dashboard marked below to check the server status (taking S19j 90T as an example).
Note: The S19j server (90T) is with fixed frequency 550 MHz. Firmware will stop running when the Temp
(Outlet) reaches to 85℃，there will be an error message “over max temp, pcb temp (real-time temp)”
shown on the bottom of kernel log page. Meanwhile, the server temperature on the dashboard interface
turns to abnormal and shows “Temp is too high”.
2. Monitor your server according to the descriptions in the following table:
Option
Description
Number of chips
Number of chips detected in the chain.
Frequency
ASIC frequency setting.
Real Hashrate
Real-time Hashrate of each hash board (GH/s).
Inlet Temp
Temperature of the inlet (°C).
Outlet Temp
Temperature of the outlet (°C).
Chip state
One of the following statuses will appear:
● The Green Icon - indicates normal
● The Red Icon- indicates abnormal

BITMAIN ANTMINER S19j Specifications

General

Hash Rate	90 TH/s
Noise Level	75 dB
Weight	13.2 kg
Network Connection	Ethernet
Algorithm	SHA-256
Efficiency	34.5 J/TH
Operating Temperature	0°C to 40°C
Voltage	220V - 240V
Power Consumption	3250 W
Dimensions	370 x 195.5 x 290 mm
Chip	BM1362
