KB-120-8 23
4 Mounting
4.1 Vibration dampers
The compressor can be rigidly mounted if there is no
risk of damage caused by vibration in the pipeline sys-
tem connected to it. Otherwise the compressor must be
mounted on vibration dampers.
Mounting the suction gas and discharge gas lines:
• Place the compressor on the vibration dampers or
mount it rigidly. In this position (= operational posi-
tion), connect the suction gas and discharge gas
lines and make sure that they are stress-free. Select
the vibration dampers according to the following
tables:
Compressor Kit number, article number
(4pieces)
Hardness
2MME-07K .. 2DME-7K 370 005 02 60 Shore
4FME-7K .. 4DME-10K 370 005 02 60 Shore
4TME-20K .. 4PME-25K 370 005 03 55 Shore
6TME-35K, 6PME-40K 370 005 03 55 Shore
2NSL-05K .. 2FSL-4K 370 000 19 43 Shore
2ESL-4K .. 2CSL-6K 370 000 20 55 Shore
4FSL-7K .. 4CSL-12K 370 000 20 55 Shore
Tab.2: Vibration dampers 2MME-07K .. 6PME-40K, 2NSL-05K .. 4CSL-12K
Compressor Kit number, art-
icle number
(2pieces)
Crankcase side
Hardness Kit number, art-
icle number
(2pieces)
Motor side
Hardness
4VSL-15K .. 4NSL-30K 370 002 11 60 Shore 370 002 10 65 Shore
Tab.3: Vibration dampers 4VSL-15K .. 4NSL-30K
