3-2-2 Using Single Battery Cradle (Optional)
1) Connect the power cord ② to the battery
charger ①.
2) Connect the battery charger ① to the
power connector of the single battery
cradle ③.
3) Plug the power cord ② into an electrical
outlet.
4) Insert the battery ④ into the single
battery cradle ③ until snaps in place.
3-2-3 Using Vehicle Charger (Optional)
1) Turn off the power to the printer.
2) Connect the vehicle charger ① to your
car’s cigarette lighter jack.
3) Open the external interface protection
cap in the direction of ②.
4) Connect the vehicle charger to the power
connector.
The printer may be seriously damaged if a
battery charger not provided by BIXOLON is
used. BIXOLON is not liable for such damage.
WARNING
Turn off the power before charging the battery
for the printer.
