BIXOLON SPP-R410 User Manual

Rev. 1.00
- 12 -
SPP-R410
3. Installation & Usage
3-1 Battery Installation
1) Insert the battery in the bottom of the
printer, and ensure that you align the
battery hook properly.
2) Push the battery into the slot until you hear
it snap in place.
NOTE
Since the battery is partially changed at the
time of purchase, charge the battery prior to
product use. (Use the battery)
3-2 Battery Charging
3-2-1 Using Battery Charger
1) Turn off the printer power.
2) Connect the power cord ② to the battery
charger ①, and then connect AC power.
3) Open the external interface cap in the
direction of ③.
4) Connect the battery charger to the power
connector.
CAUTION
The printer may incur serious damage if the
battery charger provided by BIXOLON is not
used. BIXOLON is not legally liable for any
such damages. (The voltage and electrical
current specifications of the printer and
battery charger must match.)
WARNING
Turn off the power before charging the battery
for the printer.
①
②
③

BIXOLON SPP-R410 Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Product color	Black
Maximum roll diameter	57 mm
Supported paper width	112 mm
Maximum printing width	104 mm
Printing media thickness	57 µm
Battery voltage	7.4 V
Battery recharge time	4 h
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C.
Cables included	AC
Quick start guide	Yes
Ethernet LAN	No
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	138 mm
Width	143 mm
Height	66 mm
Weight	242 g
