BIXOLON SPP-R410 User Manual

Rev. 1.00
- 25 -
SPP-R410
6. Peripherals Connection
This product can communicate with other devices via Bluetooth, Wireless LAN
communication and cable.
6-1 Bluetooth & Wireless LAN Connection
1) The printer can be connected to devices
equipped with Bluetooth communication
capacity (PDAs, PCs, etc.).
2) Use the Bluetooth connection function
supported by the device to connect to the
printer.
The NFC tag built into the printer enables
automatic pairing with devices.
NOTE
Tap your host device to logo on the side of
the printer for NFC auto pairing.
NOTE
The device must support NFC Auto Pairing.
It may display a message that the device
cannot be connected as NFC Auto Pairing
is supported up to the B/T pairing and the
devices must be connected manually, but
this is normal.
3) The printer can be connected to other
stations, such as PDAs and PCs
supporting wireless LAN communication
in Ad-hoc mode, Soft AP mode and AP
in Infrastructure mode.
NOTE
Refer to the Bluetooth Wireless LAN
Manual for detailed information on its
connection.
You can check the bluetooth environment
(authentication, encryption, connection
mode) and the wireless LAN environment
(IP, SSID, authentication, encryption) via
the self-test page.

BIXOLON SPP-R410 Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Product color	Black
Maximum roll diameter	57 mm
Supported paper width	112 mm
Maximum printing width	104 mm
Printing media thickness	57 µm
Battery voltage	7.4 V
Battery recharge time	4 h
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C.
Cables included	AC
Quick start guide	Yes
Ethernet LAN	No
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	138 mm
Width	143 mm
Height	66 mm
Weight	242 g
