BIXOLON SPP-R410 User Manual

Rev. 1.00
- 27 -
SPP-R410
7. Printer Cleaning
If the interior of the printer is dusty, print quality can decline.
In such a case, follow the instructions below to clean the printer.
1) Open the paper cover and remove the paper, if present.
2) Clean the printhead (A) using the cleaning pen. Apply the cleaning pen
from the center to the edge of the printhead (A) for cleaning.
3) Using the cleaning pen, remove the paper dust from the black mark sensor (B).
(Sensor could be located in the middle or on left or on right)
4) Do not use the printer for one to two minutes after cleaning the printhead (A) until
the cleaning agent (from the cleaning pen) has completely evaporated and dried.
5) Insert the paper and close the paper cover.
Caution
 Make sure the printer power is turned off before cleaning.
 Wait for two to three minutes after power-off before printhead cleaning because it may be very
hot.
 Do not to touch the heating region of the printhead with your hand while cleaning it.
 The printhead may be damaged by static electricity.
 Avoid scratching the printhead.
 Clean the printhead periodically if linerless paper is used. Recommended cleaning period is
after consuming twenty rolls of linerless paper (100 meters), or approximately once a week.
Print quality may be degraded or printhead life may be shortened if it is not cleaned
periodically.
Warning
 Use only the linerless paper that is provided by BIXOLON. Use of other paper voids product
warranty.
 Use only the cleaning pen (PCP-R200II) provided by BIXOLON for cleaning.
A Head
B Sesor

BIXOLON SPP-R410 Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Product color	Black
Maximum roll diameter	57 mm
Supported paper width	112 mm
Maximum printing width	104 mm
Printing media thickness	57 µm
Battery voltage	7.4 V
Battery recharge time	4 h
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C.
Cables included	AC
Quick start guide	Yes
Ethernet LAN	No
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	138 mm
Width	143 mm
Height	66 mm
Weight	242 g
