BIXOLON SPP-R410 User Manual

Rev. 1.00
- 19 -
SPP-R410
3-6 Using Control Panel
• Power Button
This button is used to turn the printer on and off.
1) When the printer is off, press this button for approximately 2
seconds to turn on the power.
2) When the printer is on, press this button for approximately 2
seconds to turn off the power.
• Paper Feed Button
To feed paper manually, press this button.
In addition, self-testing and Hexadecimal Dumping can be done.
1) Refer to “4. Self-Test” for self-test information.
2) Refer to the service manual regarding Hexadecimal Dumping.
• Battery Status LED (Blue or Red)
1) If three blue LEDs are lit, the battery is fully charged.
2) If two blue LEDs are lit, the battery is half charged.
3) If one blue LED is lit, the battery is at the lowest charge level.
4) If the red LED is lit, the battery must be charged or replaced.
• Error LED (Left-sided)
1) If the red LED is lit, the paper cover is open.
2) If the red LED is blinking, either the paper has been fully used or
the print head is overheated.
(Replace the roll of paper or turn off the printer for at least 10
minutes.)
3) If the red LED continues to blink, it may indicate a more serious
problem with the product. Call your authorized service dealer.
• Bluetooth & Wireless LAN LED (Right-sided)
1) When using Bluetooth
If the printer is ready for wireless communication with any
Bluetooth, the green LED as well as the battery status LED is
turned on.
2) When using wireless LAN
The right indicator shows the signal strength from wireless LAN.
The green LED blinks for acceptable signal strength while the
green LED blinks for weak signal strength.
 In power save mode, only the Status LED is lit.
NOTE
The power saving mode is activated after the first communication, with the
default time interval being 10 seconds.

BIXOLON SPP-R410 Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Product color	Black
Maximum roll diameter	57 mm
Supported paper width	112 mm
Maximum printing width	104 mm
Printing media thickness	57 µm
Battery voltage	7.4 V
Battery recharge time	4 h
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C.
Cables included	AC
Quick start guide	Yes
Ethernet LAN	No
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	138 mm
Width	143 mm
Height	66 mm
Weight	242 g
