BIXOLON SPP-R410 User Manual

Rev. 1.00
- 28 -
SPP-R410
8. Appendix
8-1 Specifications
Item
Description
Printing
Printing Method
Thermal printing
Print Speed
90 mm/sec (Receipt paper), 60 mm/sec (Linerless paper)
Resolution
203 DPI
Paper Supply Mode
Easy paper loading
Character Size
Font A: 12 × 24 Font B: 9 × 17 Font C: 9 × 24
Characters
Per Line
Font A: 69 Font B/C: 92
Character Set
English: 95
Expanded Graphics: 128 × 33 pages
International: 32
Barcode
1 Dimension: UPC-A, UPC-E, Code 39, Code 93, Code 128,
EAN-8, EAN-13, ITF, Codabar
2 Dimension: PDF417, Data Matrix, MaxiCode, QR code,
GS1 DataBar, Aztec Code
Emulation
BXL/POS
Windows Driver
OPOS/JPOS Driver
Windows XP SP3(32bit) / SP1(64bit) 2003 Server(32/64bit) /
VISTA(32/64 bit) / 2008 Server(32/64bit) / 7(32/64 bit) /
8(32/64bit) / 10(32/64bit)
Linux Driver
Kernel 2.6.32 and later
Windows SDK
Windows XP / 2003 Server / VISTA / 2008 Server /
7 / 8 / 10 / CE 5.0 and later
Android SDK
Android 4.0 and later
iOS SDK
iOS 8.0 and later
Utility
Unified Mobile Utility, Net Configuration Tool, Android Utility, iOS
Utility
Sensor
Paper End Sensor, Paper Cover Open Sensor,
Black Mark Sensor (Option)
Cutter Type
Tear-Bar
Language
User language supported
Paper
Paper Shape
Receipt
Linerless
Paper Type
Thermal Paper
Thermal Paper
Outer Diameter of
Paper Roll
Max. Ø 57 mm (2.24”)
Max. Ø 56 mm (2.20”)
Width
111.5 ± 0.5 mm (4.39” ± 0.2”)
111.5 ± 0.5 mm (4.39” ± 0.2”)
Thickness
0.07 ± 0.005 mm
0.08 ± 0.01mm
Reliability
Printer
50 km (Receipt paper), 10 km (Linerless paper)
Battery
Rechargeable up to 500 times
Communications
Interface
Serial / USB, Bluetooth V4.1(Classic / LE), NFC Auto paring
Wireless LAN 802.11 a/b/g/n
*Wireless communication is enabled only for devices with
Bluetooth or Wireless LAN function.
Battery
Charger
Input
Voltage: 100 ~ 240 VAC
Current: 0.5A (Max. at 110VA)
Output
Voltage: 8.4 VDC Current: 0.8A
* Charging current and charging time may depend on the
type (option) of charger.
Battery
Type
Lithium-ion
Output
Voltage: 7.4 VDC (Available 8.4 ~ 6.8VDC)
Capacity: 2600 mAh
Charging Time
Within four hours
Usage
Conditions
Temperature
Printer: -15~50℃ (5~122℉)
Battery: 0~40℃ (32~104℉)
Battery discharge: -20~60℃ (-4~140℉)
Humidity
Printer: 10~80% RH (No condensation)
Battery: 20~70% RH(Non-condensing, refer to the
temperature conditions on page 8)
Dimensions
Printer
143mm × 138mm × 66mm (5.63 in. × 5.43 in. × 2.60 in.)
Weight
Printer
Printer: 440g (0.97lbs)
Printer+Battery: 540g (1.19lbs)
Printer+Battery+Paper: 683g (1.51lbs)
Package: approx.1300g (2.87bs)
Accessories
Basic Package
Battery Pack, Battery Charger, Belt Clip, Paper, Power Cord,
CD, Installation Guide
Sold Separately
Belt Strap, Cigarette Lighter Charger, Interface Cable,
Cleaning Pen, Single Battery Cradle, Quad Battery Charger

BIXOLON SPP-R410 Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Product color	Black
Maximum roll diameter	57 mm
Supported paper width	112 mm
Maximum printing width	104 mm
Printing media thickness	57 µm
Battery voltage	7.4 V
Battery recharge time	4 h
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C.
Cables included	AC
Quick start guide	Yes
Ethernet LAN	No
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	138 mm
Width	143 mm
Height	66 mm
Weight	242 g
