BIXOLON SRP-270 Reference Guide

POS/Mobile Printer
Rev. 1.00
- 39 -
3-27 SetPrintDirectionInPM
Set the printing direction in the Page Mode.
int SetPrintDirectionInPM (int printDirection)
[Parameters]
* int printDirection
printDirection
Value
Direction
Starting Position
Rotation
PAGEMODE_ROTATE_0
48
Left -> Right
Top left
0 degree
PAGEMODE_ROTATE_90
51
Top -> Bottom
Top right
90 degrees
PAGEMODE_ROTATE_180
50
Right -> Left
Bottom right
180 degrees
PAGEMODE_ROTATE_270
49
Bottom -> Top
Bottom left
270 degrees
[Return Values]
Constant
Value
Description
SUCCESS
0
The function is successful.
WRITE_ERROR
-105
Data transmission failed.
BAD_ARGUMENT
-117
The specified argument is not correct.
NOT_SUPPORT
-124
The function is not supported.
* Example
ConnectToPrinter(………..);
……
// Select Page Mode
if (SelectPageMode(true) != SUCCESS)
return;
SetPrintAreaInPM(0, 0, 416, 416);
SetPrintDirectionInPM(PAGEMODE_ROTATE_90);
……
PrintDataInPM();
