Operating instructions VS12 /C /F /F-P /W About this machine
6.080.98.5.10.13 en 2 - 3
2
Noise level
During normal operation, the noise emission value according to DIN EN 11202 at the
workstation is lower than 70 dB(A), related to the entire machine.
In sharpening mode, the noise level reaches temporarily up to 74 dB(A).
Vibration
The total vibration of the items, which get into contact with hand and arm is below 2.5 m/s
2
and therefore below the required limited value.
2.2.1 Name of components VS12
Fig. 1: Name of components VS12
The machine is available in different versions. The figure shows an example:
Blade guard ring
Blade
Blade cover
Pusher protection
Back panel
