Operating instructions VS12 /C /F /F-P /W Technical data
6.080.98.5.10.13 en 9 - 5
9
Weight = approx. 53 kg = 117 lb
Blade diameter
= 350 mm = 13.8"
Blade speed = 266 rpm
max. product size, diam-
eter
= 270 mm = 10.6"
Max. product height = 320 x 260 mm = 12.6" x 10.2"
Slice thickness setting = 0.5 to 24 mm = 0.02" to 0.95", stepless
Types of current, voltag-
es, power consumptions
= see rating plate
9.5 Dimensions VS12F37-P
Fig. 67: VS12F37-P, example
The machine is available in different versions. The figure shows an example:
Outer dimensions:
Length
= 726 mm = 28.6"
Width
= 695 mm = 27.4"
Height
= 546 mm = 21.5"
Installation surface:
Length
= 605 mm = 23.8"
Width
= 430 mm = 17"
