Technical data Operating instructions VS12 /C /F /F-P /W
9 - 4 6.080.98.5.10.13 en
9
max. product size, diam-
eter
= 270 mm = 10.6"
Max. product height
= 360 x 290 mm = 14.2" x 11.4"
Slice thickness setting = 0.5 to 24 mm = 0.02" to 0.95", stepless
Types of current, voltag-
es, power consumptions
= see rating plate
9.4 Dimensions VS12F-P
Fig. 66: VS12F-P, example
The machine is available in different versions. The figure shows an example:
Outer dimensions:
1
Length
= 706 mm = 27.8"
2
Width
= 695 mm = 27.4"
3
Height
= 536 mm = 21.1"
Installation surface:
4
Length
= 605 mm = 23.8"
5
Width
= 430 mm = 16.9"
Work area:
6
Length
= 890 mm = 35"
7
Width
= 730 mm = 38.4"
