Maintenance Operating instructions VS12 /C /F /F-P /W
8 - 4 6.080.98.5.10.13 en
8
Load plate VS12W
Fig. 39: Load plate VS12W
Pull weighing platform towards operator
until guide bolts are loose and remove
upwards.
Bias cut plate VS12, VS12W (option)
Lever up bias cut plate upwards.
Place the product holder on the carriage.
Carriage
Fig. 40: Tilt the carriage to the outside
Turn out knob on carriage foot.
Tilt the carriage to the outside.
