Operating instructions VS12D /C /-R /-V /-
V/R
Operation
6.083.98.5.10.10 en 6 - 5
6
6.3 Slicing with round platter (optional)
WARNING The round platter is equipped with magnets to ensure a fast and
easy mounting.
If the distance to the magnet is lower than 50 mm, pacemakers can
be affected.
– People with pacemakers should consult a doctor before operating
the machine.
Remove depositing table
Fig. 23: Remove depositing table
Pull depositing table towards you until it
stops, in vertical position lift up towards
you and remove to the top.
Installing round platter
Fig. 24: Installing round platter
Install round platter in guide shaft from
the top.
If necessary, turn until round platter is
engaged.
Once the round platter is attached, the
machine automatically switches to de-
positing program <Circular pattern> and
the table moves to its initial position.
Load and slice product, see chapter 6.1 or 6.2.
