Maintenance Operating instructions VS12D /C /-R /-V /-
V/R
8 - 14 6.083.98.5.10.10 en
8
Product fixation device VS12D
Fig. 53: Product fixation device VS12D
On the operator side, place product
holder fixation device horizontally on to
the guide shaft and move on guide
shaft.
Remnant holder plate VS12D
Fig. 54: Remnant holder plate VS12D
Attach remnant holder plate to product
holder by taking the fixation into ac-
count.
For quick and easy handling, the remnant
holder is attached to the pusher guard by
a magnet lock.
If the distance is less than
50 mm, pacemakers can be affected.
Place the product holder on the car-
riage.
Product holder, complete VS12D-V
Fig. 55: Product holder VS12D-V
Install complete product holder to fixa-
tion from the top.
Screw tight with the star grip screw.
