SPECIFICATIONS
FREQUENCY CHARACTERISTICS
Waveforms Sine, Square, Triangle, ± Pulse, ± Ramp
Range 0.1Hz to 10MHz in 8 ranges
Resolution 5 digits
Tuning Range Coarse: 10:1, Fine: ±5% of Coarse Setting
Variable Duty Cycle 15:85:15 Continuously Variable
Operating Modes Normal, Sweep, VCG
Frequency Stability Output will change less than 0.09%
over 15 minutes after 1 hour warmup.
OUTPUT CHARACTERISTICS
Impedance 50Ω ±10%
Level 20V p-p Open-circuit, 10V p-p into 50Ω
Amplitude Control Variable, 20 dB range typical
Attenuation -20dB ±1 dB
DC Offset
Preset: ±0.1V typical
Variable: ±10V open-circuit, ±5V into 50 Ω
SINE WAVE
Distortion 3% typical at 1kHz
Flatness (into 50 Ω) ±5% (.45 dB) 0.1Hz to 8MHz, ±20%
(2.0 dB) 8MHz to 10MHz
SQUARE WAVE
Symmetry 0.1Hz to 100kHz ≤2%
Rise Time ≤30nS
TRIANGLE WAVE
Linearity ≥98% to 100kHz
TTL OUTPUT
Level 0.8V to 2.4V
Rise Time ≤20nS
Duty Cycle 50% typical
CMOS OUTPUT
Max Frequency 2MHz
Level 4V to 14V ±0.5V p-p,
Continuously variable
Rise Time ≤120nS
VCG (Voltage Controlled Generator) INPUT
Input Voltage 0 - 10V ±1V causes a 100:1
frequency change
Impedance 10kΩ ±5%
