Check whether the input power is within the rated power range or the programmed protection ranges. If it is out-
side the range, disconnect the device under test. Then press any key on the front panel or remotely send command
PROTection:CLEar. The OPP displayed on the front panel will turn o and the electronic load exits OPP protection
state.
To start a OPP test, press “[ ]+ [ ]” (Trigger).
Press “[ ]+ [CW]” (OPP) to enter OPP test operation.
OPP TEST RUN
OPP TEST
STOP Run OPP test le
CALL OPP TEST
Recall OPP File=1 Recall OPP test le(range le1-le10)
EDIT OPP TEST
1. VON LEVEL=0.000V - - Set Voltage on value
2. VON DELAY=0.01S - - Set Voltage on delay time
3. RANGE=5A - - Set working current range
4. START =0.1W - - Set start power value
5. STEP =1W - - Set step power value
6. STEP DEL=1S - - Set step delay time
7. END =12W - - Set cut-o power value
8. OPP VOLT=7V - - Set OPP value
9. MAX TRIP =6.5W - - Upper limit of OPP value
10. MIN TRIP =5.6W - - Lower limit of OPP value
11. SAVE OPP FILE=1 - - Save OPP test le
Set the power on mode to be OPP test mode
Operation - Display on front pannel
1. Press “[ ]+ [ 8 ]” (system) enter into sysmtem menu - 0.0000V 0.000A POWER-ON BUZZER
2. Press right key,select RUNMODE and - 0.0000V 0.000A RUN <NORMAL> conrm with “ ” button -
3. Press direction key to OCP_TEST,Press “ ” to conrm. - select - 0.0000V 0.000A RUN <OPP_TEST>
4. Press “[ Esc ]” button to quit the set. - - 0.0000V 0.000A STOP 0.000A
After above steps,press [ ]
name:
images/triggerButton
file:
images/triggerButton
state:
unknown
button to run OPP test le.
8.5.17 Recall OPP File
1. Press “[ ]+ ” button to select programe le,the panel displays “CALL OPP FILE= 1”. Enter the le
name(1-10), press button to conrm.
2. According to the following steps to escape OPP mode:press [ ]+ [8]
