Ventless Hood System Replacement Parts
21
Figure 2. Blower Motor Assembly – Continued
Table 2. Blower Motor Assembly Parts List
ITEM # PART # QTY DESCRIPTION
1 M0052 1 MOTOR, BLOWER 1/2 HP LEESON
2 F0024 16 RIVNUT, #10-24
3 TP0021 36” TAPE, ARMAFLEX 1/8 X 3/4 X 50'
4 WSH037 4 WASHER, 3/16 SAE FLAT
5 NUT049 8 NUT, 8-32 HEX
6 SP0013 4 SPACER, FOR #8 X 1/2" LG.
7 FN0005 1 HOUSING, BLOWER CLOCKWISE
8 FN0004
OR
FN0019
1
OR
1
WHEEL, BLOWER 5 3/4 CLKWS RT.
OR
BLOWER WHEEL, 50HZ FH HOODS
9 FB37115200 1 CONDUIT, 1/2" FT0323 10"
10 FT0320 2 COMPRESSION FTG, 1/2" STRAIGHT
11 FN0006
OR
FN0020
1
OR
1
WHEEL, BLOWER 5-3/4 CTCKWS LT
OR
BLOWER WHEEL, 50 HZ FH HOODS
12 FN0007 1 HOUSING, BLOWER C'TR CLK WISE
13 SCR004 6 SCREW, 8 X 3/8 PHIL TRUSS HD
14 FB37113602 1 PLATE, LEESON FAN MOUNTING
15 SCR137 8 SCREW, 10-24 X 5/8 SLTD TRUSS
