9
ENGLISH
(Original instructions)
@
WARNING! Before drilling into walls, oors or
ceilings, check for the location of wiring and pipes.
@
WARNING! Do not apply chisels when the tool is in
the drilling mode.
Forward/reverse action (g. I)
u Move the selector (2) to indicate the direction you require.
Switching on and off (g. I)
u To switch the tool on, press the variable speed switch (1).
The tool speed depends on how far you press the switch.
u As a general rule, use low speeds for large diameter drill
bits and high speeds for smaller diameter drill bits.
u To switch the tool off, release the variable speed switch.
Selecting the operating mode (g. J)
The tool can be used in three operating modes.
u To operate the operating mode selector (3), push the
unlock button (20) and rotate the selector towards the
required position, as indicated by the symbols.
Drilling
u For drilling in steel, wood and plastics, and for
screwdriving set the operating mode selector (3) to the
r
position (19).
Hammer drilling
u For hammer drilling in masonry and concrete, set the
operating mode selector (3) to the
qr
position (18).
When hammering, the tool should not bounce and run
smoothly. If necessary, increase the speed.
Hammering
u For hammering with spindle lock, and for light chiselling
and chipping, set the operating mode selector (3) to the
q
position (21).
u When changing from hammer drilling to chiselling, turn the
chisel to the desired position. If resistance is felt during mode
change, slightly turn the chisel to engage the spindle lock.
Accessories
The performance of your tool depends on the accessory used.
Stanley BLACK+DECKER accessories are engineered to high
quality standards and designed to enhance the performance
of your tool. By using these accessories you will get the very
best from your tool.
Maintenance
Your BLACK+DECKER corded/cordless appliance/tool has
been designed to operate over a long period of time with a
minimum of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance on corded /
cordless power tools:
u Switch off and unplug the appliance/tool.
u Or switch off and remove the battery from the appliance/
tool if the appliance/tool has a separate battery pack.
u Or run the battery down completely if it is integral and then
switch off.
u Unplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
u Regularly clean the ventilation slots in your appliance/tool/
charger using a soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
u Regularly open the chuck and tap it to remove any dust
from the interior (when tted).
Mains plug replacement (U.K. & Ireland only)
If a new mains plug needs to be tted:
u Safely dispose of the old plug.
u Connect the brown lead to the live terminal in the new plug.
u Connect the blue lead to the neutral terminal.
@
WARNING! No connection is to be made to the earth
terminal. Follow the tting instructions supplied with
good quality plugs. Recommended fuse: 5 A.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be recovered or
recycled, reducing demand for raw materials.
Please recycle electrical products and batteries according to local
provisions. Further information is available at www.2helpU.com
Technical data
BCD900D1S / D1K BCD900E2K BCD900M1K BCD900B
Input voltage V
DC
18 18 18 18
No-load speed min
-1
0 - 1800 0 - 1800 0 - 1800 0 - 1800
Impact rate min
-1
0 - 6350 0 - 6350 0 - 6350 0 - 6350
Weight kg
2.60 2.60 2.87 2.22
Max. drilling capacity
Concrete mm
18 18 18 18
Steel mm
13 13 13 13
Wood mm
25 25 25 25
Battery
BL2018 BL2518 BL4018 Not Supplied
Voltage V
DC
18 18 18
Capacity Ah
2.0 2.5 4.0
type
Li-Ion Li-Ion Li-Ion
