6
ENGLISH
(Original instructions)
7
ENGLISH
(Original instructions)
Should you nd one day that your BLACK+DECKER product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product avail-
able for separate collection.
z
Separate collection of used products and
packaging allows materials to be recycled and
used again.
Re-use of recycled materials helps prevent en-
vironmental pollution and reduces the demand
for raw materials.
Local regulations may provide for separate collection of elec-
trical products from the household, at municipal waste sites or
by the retailer when you purchase a new product.
BLACK+DECKER provides a facility for the collection and re-
cycling of BLACK+DECKER products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local BLACK+DECKER ofce at the
address indicated in this manual. Alternatively, a list of author-
ised BLACK+DECKER repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Batteries
Z
There are no user servicable parts inside.
u At the end of your products life return the whole unit to
your service agent or to a local recycling station to have
the battery recycled. Do not throw the unit out with house-
hold waste.
Technical data
BDCD8
Voltage V
DC
7.2
No-load speed Min
-1
400
Max. torque Nm 8/12
Chuck capacity mm
1-10
Max Drilling capacity
Steel/wood mm NA/20mm
Weight kg
0.62
Charger
QW:90623494,
GB: 90623492
Input voltage V
AC
230
Output voltage V
DC
5
Current mA
600
Approx. charge time Hours
8
Battery BL4018
Voltage V
AC
7.2
Capacity Ah 1.5
Type Li-Ion
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 60.7 dB(A), uncertainty (K) 3 dB(A)
Sound power (L
WA
) 71.7 dB(A), uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according to EN 60745:
Drilling into metal (a
h, D
)0.837 m/s
2
, uncertainty (K) 1.5 m/s
2
Screwdriving without impact (a
h
) 0.837 m/s
2
, uncertainty (K) 1.5 m/s
2

Black & Decker BDCD8 Specifications

General

Soft grip	Yes
Chuck type	Keyless
Product design	Pistol grip drill
Number of gears	2
Torque settings	8
Sound power level	84 dB
Chuck capacity (max)	10 mm
Chuck capacity (min)	1 mm
Sound pressure level	73 dB
Idle speed (1st gear)	400 RPM
Drilling diameter in wood (max)	20 mm
Maximum torque (hard applications)	8 N⋅m
Maximum torque (soft applications)	12 N⋅m
Vibration emission	2.5 m/s²
Product color	Black, Orange
Power source	Battery
Charging time	180 min
Battery voltage	7.2 V
Battery capacity	1.5 Ah
Battery technology	Lithium
Carrying case	No
Quantity per pack	1 pc(s)
