Black & Decker LST136 - Assembly & Adjustment; Attaching the Guard; Attaching the Auxiliary Handle; Adjusting Auxiliary Handle Position

tabclicksintoplace(Ensure
thattheguiderails(D1)on
theguard(D2)arecorrectly
alignedwiththeguiderails
(D3)onthetrimmerhead(D4)
(figure D). Thelockingtab(D5)
shouldsnappedintothehousing
slot(D6).
 •Securetheguardwiththe
screw(E1)(figure E).
ATTACHING THE AUXILIARY
HANDLE (FIGURES F AND G)
 •Pushtheauxiliaryhandle
(F1)ontothetube(F2).
 •Slidethebolt(G1)through
theholesintheauxiliary
handle.
 •Tightentheknob(G2)
ontotheboltbyturningit
clockwise.
ADJUSTING THE POSITION
OF THE AUXILIARY HANDLE
(FIG. G)
 Theauxiliaryhandlecanbe
adjustedtoprovideoptimum
balanceandcomfort.
 •Loosentheknobonthe
boltbyturningitcounter
clockwise.
 •Gentlyslidetheauxiliary
handleupordownthetube
tothedesiredheight.
 •Tightentheknobontothe
boltbyturningitclockwise.
8
WARNING: Beforeassembly,makesurethatthetoolis
switchedoffandthebatteryhasbeenremoved.
ASSEMBLY TOOLS REQUIRED (NOT SUPPLIED):
-PhillipsScrewdriver
WARNING: Removethebatterybeforeattemptingtoattachany
ofthefollowingcomponents.
ATTACHING THE GUARD
(FIGURES D AND E)

WARNING: NEVER
OPERATETOOLWITHOUT
GUARDFIRMLYINPLACE.
Theguardmustalwaysbe
properlyattachedonthetoolto
protecttheuser.
 •Removethescrewfromthe
guard.
 •Keepingtheguardsquareto
thetrimmerheadslideitfully
intoplaceuntiltheretaining
E
E1
F
F1
F2
ASSEMBLY & ADJUSTMENT
G
G2
G1
D
D2
D1
D3
D4
D6
D5
LI-ION Battery Packs and Chargers
Thisproductcanacceptanyofthebatteriesand
chargerslistedinthechartbelow.
Batteries:LI-ION    LBX36
     LBXR36
     LBXR2036
Chargers:LI-ION   LCS36
     LCS436
Description Cat. #
