ADVANCED VIDEO SCALER
6. Output Timing Specifications
The timing specifications for the six output resolutions follow VESA specifications
or Macintosh specifications where applicable. The 852 x 480 specification is based
on the Fujitsu 42” plasma display specification.
Resolution Refresh H (KHz) V (Hz)
640 x 480 60 31.48 59.96
640 x 480 75 37.51 75.03
852 x 480 60 31.73 59.98
852 x 480 75 38.07 71.97
800 x 600 60 37.89 60.33
800 x 600 75 46.89 75.02
832 x 624 60 39.29 60.07
832 x 624 75 49.19 75.10
1024 x 768 60 48.38 60.19
1024 x 768 75 60.04 75.05
1280 x 1024 60 64.00 60.04
NOTE
The Advanced Video Scaler does not support 1280 x 1024 at 75 Hz
refresh.
