Chapter 5: Operation
5. Operation
5.1 Display and Controls
5.1.1 Front, Back, and Top of the Quad Laser Source
Figure 5-1 shows the back and top of the instrument. Table 5-1 describes its
components.
1 2
3
4
5 6
7
Figure 5-1. Front, back, and top.
