CHAPTER 1: SPECIFICATIONS
TABLE 1-2. RECEIVER SPECIFICATIONS
Console Connection
Video Output
KVXLCDP-100, KVXLCDPF-100: (1) DisplayPort female;
KVXLCDP-200, KVXLCDPF-200: (2) DisplayPort female
Serial Control Port (1) DB9 male
Host Connection
Video Input N/A
Link Port
RJ-45 (KVXLCDP-100 receiver) CATx cable – max. length: 330 feet (100 meters)
SFP (KVXLCDPF-100 receiver)
Fiberoptic cable – max. length: 18.6 miles (30 km), depending on SFP
NOTE: The SFP module is not included. Must be ordered separately.
USB Interface
Host N/A
Device (4) USB 2.0 Type A female for USB device extension
Audio
2-way analog audio (1) MIC In, (1) Speaker Out
Serial
RS-232 Extension Port (1) DB9 male
General
LED indicator
Power: Red LED:
Link: Green LED
DDC Supported DDC, DDC2, DDC2B
Max. Video Resolution 4K @ 30 Hz, 3840 x 2160 @ 30 Hz (8-bit output only)
OS Compatibility OS Independent
Housing material Chassis Metal
Operating Temperature 32 to 122° F (0 to 50° C)
Storage Temperature -4 to +140° F (-20 to +60° C)
Relative Humidity 0 to 80%
Power Supply External 5-VDC, 2-A power supply
Dimensions
KVXLCDP100, KVXLCDPF-100: 0.83" H x 7.09" W x 3.27" D (2.1 x 18 x 8.3 cm)
KVXLCDP-200, KVXLCDPF-200: 1.71" H x 7.09" W x 3.27" D (4.4 x 18.0 x 8.3 cm)
Weight
KVXLCDP-100 receiver: 0.82 lb. (0.372 kg);
KVXLCDPF-100 receiver:0.83 lb. (0.378 kg) (no SFP);
KVXLCDP-200 receiver: 0.85 lb. (0.386 kg);
KVXLCDPF-200 receiver: 0.85 lb. (0.386 kg) (no SFP)
