Chapter 1: Specifications
1. Specifications
Table 1-1. Specifications
Technology
Standards IEEE 802.3, 10BASE-T;
IEEE 802.3u, 100BASE-TX;
IEEE 802.3x, full-duplex and flow control
Forward and Filtering Rate 10 Mbps: 14,880 pps;
100 Mbps: 148,810 pps
Processing Type Store-and-Forward,
Half-duplex back pressure,
and IEEE 802.3x full-duplex flow control
Auto-negotiation Auto MDI/MDI-X
Power
Input 12 to 48 VDC (terminal block)
Consumption 4.2 W max.
Mechanical
Casing Aluminum case, IP30
Dimensions 3.94"H x 1.65"W x 3.54"D (10 x 4.2 x 9 cm)
Weight 0.9 lb. (0.41 kg)
Mounting DIN-rail (top hat type 35 mm) or wallmounting
Interface
Connectors Ethernet Port:
(1) 10/100BASE-TX port,
Ethernet Extender Port:
(1) RJ-11 and terminal block port;
DIP Switch DIP Switch 1:
Auto/Local mode,
DIP Switch 2:
ON/OFF LInk Down relay
LED Indicators Per unit:
Power 1, 2
Ethernet Extender port:
Link/Activity,
Line Speed;
10/100BASE-TX port:
Link/Activity,
Speed
