SERVSWITCH DUO™
RS-232 serial mice: These require a special adapter, with the pinning shown in the
illustration below, to connect the ServSwitch Duo’s PS/2 mouse port to the RS-232
port on a PC. One of these adapters is included with your Switch for each four
CPU ports it has. PS/2 type mouse cables, such as the mouse strand of our CPU
Extension Cables (see Section 3.3), should be no longer than 100 ft. (30.5 m). If
you are using a converter at the Switch end instead of the PC end and are running
regular RS-232 cable, this should not be longer than 50 ft. (15.2 m).
1
2
3
4
5
6
1
2
3
4
5
6
7
8
9
6-pin mini-DIN attaches to
Switch or cable from Switch
N/C
RLSD (DCD)
RD
KDAT
TD
SGND
+5V
KCLK
-12V
TD (-12V)
DTR
SGND
DSR
RTS
CTS
RI
N/C
N/C
DB9 attaches to PC’s serial port or
cable to PC’s serial port
12
2
3
4
4
3
56
65
Female
Male
1
1
Male
Female
5
69
51
96
