Black Box ServSwitch User Manual

39
CHAPTER 3: Installation and Preconfiguration
3.5.1 T HE P OWER -U P D IAGNOSTIC S CREEN : S TANDARD M ESSAGES
The diagnostic screen that appears when you turn ON the Matrix ServSwitch is
shown in Figure 3-5; standard messages you might see on it are shown in Table 3-4
on the next page.
Figure 3-5. The diagnostic screen.
Welcome to Matrix ServSwitch
Power on diagnostics
Kernel version KX14E
Overlay version O42B
Kernel program Good
Static RAM Good
Configuration Good
Board number 2
Communication ID 6
Communication Good
Local ports 8
Program version MX16H
Main program Good
PC keyboard detected
PS2 mouse detected
