16
MATRIX SERVSWITCH™
2.3 The Front Panel
The Switch’s front panel features two pushbutton switches and several LED
indicators. To familiarize yourself with these controls and indicators, refer to
Figure 2-1 and the descriptions that follow on the next page.
Figure 2-1. The front panel of a 2 x 16 Matrix ServSwitch (SW743A-R3).
Power
5
6 7
8
1
2 3
4
9
10 11
12
13
14 15
16
