724-746-5500 | blackbox.com
Page 10
Chapter 2: Overview
NOTES:
1. The claimed transmission distance here depends on the installed cable grade,
source device, and display.
2. For CAT5/coax transmission, you must use a solid cable, not stranded cable.
Any keystone jack along the transmission path will decrease the transmission
performance significantly.
2.3 What’s Included
Your package should contain the following items. If anything is missing
or damaged, contact Black Box Technical Support at 724-746-5500
or info@blackbox.com.
• (1) Transmitter
• (1) Receiver
• (2) 5-VDC, 2-A wallmount power supplies
• This user’s manual
2.4 Hardware Description
2.4.1 Transmitter
Figures 2-1 and 2-2 show the transmitter’s front and back panels. Table 2-1
describes its components.
1 2
Figure 2-1. Transmitter front panel.
