724-746-5500 | blackbox.com Page 15
Chapter 2: Overview
2.5 Typical Configuration
VX-HDMI-TP-3D40M
Transmitter
VX-HDMI-TP-3D40M
Receiver
CATx cable
HDMI
cable
HDMI
cable
CATx cable
Figure 2-3. Connection diagram.
