Black Box VX-HDMI-TP-3D40M User Manual

724-746-5500 | blackbox.com
Page 12
Chapter 2: Overview
Table 2-2. EDID mode switch options.
Number Video Audio
0
[Video]—2D/Full-HD 24-bit
1080p@60
[Audio]—up to 7.1 ch
surround sound
1
[Video]— 2D/Full-HD 24-bit
1080p@60
[Audio]—up to 2.0 ch
surround sound
2
[Video]—2D/Full-HD 36-bit
1080p@60
[Audio]—up to 7.1 ch
surround sound
3
[Video]—2D/Full-HD 36-bit
1080p@60
[Audio]—up to 2.0 ch
surround sound
4
[Video]—2D/HD 24-bit
(1080p@30)(1080i@60)
(720p@60)
[Audio]—up to 7.1 ch
surround sound
5
[Video]—2D/HD 24-bit
(1080p@30)(1080i@60)
(720p@60)
[Audio]—up to 2.0 ch
surround sound
6
[Video]—3D/Full-HD 36-bit
(1080p@60)
[Audio]—up to 2.0 ch
surround sound
7
[EDID Learning Mode]—learns
EDID from the display
Plug in a CAT5/5e/6 cable
that will link to the receiver.
