Black Nova ARIA - Page 11

ARIA and ALBA KNX Keypad Panels - Operation and Maintenance Manual
Page 10/21
Persentase
[0..100%]
Unsigned 2bytes
[0..65535]
Signed 2 bytes
[-32768..32767]
2 bytes
2 bytes
Scene
-
Control and store up to 64 scenes
Scene number
Store scene
1 byte
1 bit
Edges
function
Normal
(press,
release)
Send values at press and release events to up to 2 objects
Object A
Object B
Different depths available
On/Off
Dimming
Value [0..255]
Value [0..100%]
1 bit
4 bits
1 byte
2 bytes
Extended (+
short and
long press
operation)
Send values at short press, release after short press, long press and
release after long press events to up to 2 objects
Grouping
Control
functions
Light
selector
When “Group control” is enabled the function sets the button as light
selector and additional are available
Light control
ON/OFF
Light control
Dimming
Light control value
[0..100%]
1 bit
4 bits
1 byte
Decrease press
● Short press: OFF
Long press: Decrease
● Short press: Decrease
Long press: OFF
● Long press decrease
● Short press decrease
Increase press
● Short press: ON
Long press: Increase
● Short press: Increase
Long press: ON
● Long press increase
● Short press increase
Step
Set step percentage value
Long pressing time
The long press is detected after the select amount of time
Stop telegram after release
Stop sending telegram if the button is released
Send dimming level cyclically
If long press is active the defined parameter set how often the
command is sent
Value ON (%)
Set the value for ON command
Value OFF (%)
Set the value for OFF command
Shutter
selector
When “Group control” is enabled the function sets the button as curtain
selector and additional are available
Shutter control
direction
Shutters control
stop
1 bit
1 bit
