Understanding the Control Panel
21
720 Formats
The 720 Format button will indicate that the line rate of the input or output is 720. When chosen as the
output format, the P button will turn GREEN automatically, as a Progressive frame is the only permissible
type for 720 signals. You can then select a frame rate of either 59.94 (for 720p59.94) or 50 (for 720p50) to
define the desired output format.
1080 Formats
The 1080 Format button will indicate that the line rate of the input or output is 1080. When 1080 is chosen
as the output format, the P, I and PSF buttons are all permissible frame types. Select your desired output
Frame type, and then select the desired Rate button to finalize the output format selection. If you select a
frame rate that is not permissible for a given Line rate and Frame type, the buttons for the valid rates will
flash green momentarily. When a format supports both 4:2:2 and 4:4:4 sampling, these options must be
selected in the Video/Output Sampling page of the Setup Menu. In addition, a setting for single link or
dual link I/O is provided in the Video Setup Menu. The settings you choose will be “remembered” and will
be used as default settings until you make a different output selection.
2K 1080 Formats
The 2K 1080 video formats are not currently available. They will be added in a future software release.
444 - RGB
1080159.94
Change Output Mode
Cancel
Accept
1080i59.94: 4.4.4 sampling,
RGB component
422 - YCbCr
1080159.94
Change Output Mode
Cancel
Accept
1080i59.94: 4.2.2 sampling,
YCbCr component
720p59.94
Change Output Mode
Cancel
Accept
