BLACKMER LB362D - Tool List; Bolt Torque Table

MAINTENANCE
CB5A-021 page 12/24
TOOL LIST
Description
Used For:
Blackmer Wrench 798016
Valve Hold-down screw Torque Tool
Blackmer Packing Installation Tool
790536 for 160 and 360 Series Compressors
790538 for 600 Series Compressors
Rod-packing protection during installation.
Blackmer Torque Wrench Adaptors
798003 for LB160 Series Compressors
798004 for LB360 Series Compressors
798007 for LB600 Series Compressors
Piston, Piston Nut
Blackmer Wrenches
798015 for 160 and 360 Series Compressors
798017 for 600 Series Compressors
Packing Box Hold-down Ring Torque Tool
3" Adjustable Spanner with 1/4" pins
Blackmer PN 790316
Piston Nut, Piston, Packing Box Hold-down Ring
9/16", 5/8" or 3/4" End Wrench
Cylinder and Crosshead Guide
1-1/16" Wrench or Socket
Valve Caps
Allen Wrenches: 3/16", 1/4", 3/8"
Valves
Sockets: 7/16", 1/2", 9/16", 5/8", 3/4", 7/8"
Various
Internal Snap Ring Pliers
Seal Replacement
Feeler gauges or Depth Micrometer
Piston Clearance
Screwdriver, Flat Blade
Nameplate screws, Packing Installation
Pliers
Rubber Mallet
Arbor Press
Wrist Pin Removal
Bearing Puller
Crankshaft Bearings
Torque Wrench
Various
Hoist (useful)
Cylinder and Crosshead Guide
Table 6 - TOOL LIST
BOLT TORQUES FOR BLACKMER COMPRESSORS LBS-FT (Nm)
Size
Con.
Rod
Bolt
Bearing
Carrier
Bearing
Cover
Plate
Crank-
case
Inspec.
Plate
Oil
Pump
Cover
Cross
Head
Guide
Cylinder
Head
Piston
&
Nut
Valve
Cover
Plate
Valve
Hold
Down
Screw
Valve
Cap
Packing
Box
Hold
Down
Ring
160
30
(40.7)
30
(40.7)
35
(47.5)
7
(9.5)
12
(16.3)
25
(33.9)
25
(33.9)
20
(27.1)
40
(54)
--
120
(163)
80
(108)
75
(102)
360
35
(47.5)
30
(40.7)
35
(47.5)
7
(9.5)
12
(16.3)
35
(47.5)
35
(47.5)
40
(54))
40
(54)
35
(47.5)
80
(108)
80
(108)
75
(102)
600
45
(61)
30
(40.7)
40
(54)
7
(9.5)
12
(16.3)
40
(54)
40
(54)
40
(54)
60
(81)
35
(47.5)
80
(108)
80
(108)
75
(102)
Table 7 - Bolt Torque
