Page 14
SET UP & USE
Horizontal Louvers
Control Panel
1. POWER: Turn on the unit by rotating the MODE dial to the desired COOLING or FAN
setting. Turn the dial to OFF at any time to shut OFF the unit.
2. COOLING MODE:
automatically go to high and circulate the cool air throughout the room. The fan will
operate on low in LO COOL mode.
3. THERMOSTAT: Turn the TEMP dial to set the desired temperature setting 1-7. For
4. FAN MODE: For fan only modes, choose either HI FAN or LO FAN. The thermostat will
not operate when in fan mode.
NOTE: To minimize wear and tear on the air conditioner, always wait at least 3 minutes
before changing modes. This will help prevent the compressor from overheating
and the circuit breaker from tripping.
PARTS & FEATURES
TEMPERATURE
min
cool
max
cool
COOLING
1
4
5
6
7
2
3
lo
fan
lo
cool
hi
cool
hi
fan
OFF
FilterMode Dial
