ENGLISH
8
• Install the storage case by sliding it into the foot of
thescrewdriver.
NOTE: Do not open storage case while attached to
screwdriver. First remove storage case from the screwdriver
and thenopen.
Fig. G
10
SCREW DRIVING
For driving fasteners, the forward/reverse/lock-off slider
should be pushed to the left. Use reverse (slider pushed to
the right) for removing fasteners. When moving from forward
to reverse, or vice versa, always release the trigger first.
Release trigger when the fastener is at the desireddepth.
NOTE: For best performance, #8, 2” fasteners are
recommended, or screw into pre-drilled holes (1/16 - 5/32
bitrecommended).
DRILLING
• Insert the appropriate hex shank drillbit.
• Select forwardrotation.
GENERAL DRILLING TIPS
• This tool is not recommended for drilling inmasonry.
• Use sharp drill bits only
• Drill bits for metal can be used for drilling holes in wood.
These bits must be sharp and should be pulled out
frequently when drilling to clear chips from theflutes.
• Support and secure work properly, as instructed in the
safety Instructions.
• Use appropriate and required safety equipment, as
instructed in the safety instructions.
• Secure and maintain work area, as instructed in the
safety instructions.
• Use light pressure until the hole is started enough to
keep the drill bit from slipping out ofit.
• Apply pressure in a straight line with the bit. Use
enough pressure to keep the bit biting but not so much
as to stall the motor or deflect thebit.
• Hold the tool firmly to control its twistingaction.
DO NOT CLICK THE TRIGGER OF A STALLED TOOL OFF AND
ON IN AN ATTEMPT TO START IT. DAMAGE TO THE TOOL
CAN RESULT. To remove:
• Put tool in reverse and back drill bitout.
Troubleshooting Guide
BE SURE TO FOLLOW SAFETY RULES AND INSTRUCTIONS
For assistance with your product, visit our website www.blackanddecker.com for the location of the service center nearest
you or call the BLACK+DECKER help line at 1-800-544-6986.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
- Unit will notstart. - Battery pack notcharged.
- Internal componets toohot.
- Check battery pack
chargingrequirements.
- Allow tool to cooldown.
- Battery will notcharge. - Jack plug not inserted
intochargeport.
- Charger not pluggedin.
- Surrounding air temperature
too hot or toocold.
- Insert jack plug into chargeport.
- Plug charger into a working
outlet. Refer to "Important
charging notes" for
moredetails.
- Move charger and battery
pack to a surrounding air
temperature of above 40
degrees F (4,5°C) or below 105
degrees F (+40,5°C).
- Unit shuts offabruptly. - Battery has reached its
maximum thermallimit.
- Out of charge. (To maximize
the life of the battery pack it is
designed to shut off abruptly
when the charge is depleted.)
- Allow tool to cooldown.
- Insert jack plug into charge
port and allow tocharge.
