ENGLISH
5
2. Attach a nozzle as described in the "Universal valve
adapter"section.
3. Insert the nozzle into the object beinginflated.
4. Press the high-pressure side of the main power
switch
1
, indicated by the tire symbol
22
.
5. To turn off, push the power switch to the centerposition.
Figure D
22
21
Deflate using the high-volume hose
(Fig. E)

WARNING: Beware of objects being ejected.
When deflating, large amounts of air will exit the
high-volume pump inflate connection
6
. Ensure the
high-volume pump inflate connection is not pointed
at anyone oranything.
1. Remove the high-volume hose
10
from the
storagelocation.
2. Line up the notches 
19
of the hose with the nubs 
23
of
the high-volume pump deflate connection 
7
. Then, slide
the hose on and twist counter-clockwise tosecure.
3. Insert the hose, or it's tapered nozzle
11
into the object
beingdeflated.
4. Press the high-volume side of the main power switch
1
,
indicated by the air mattress symbol
21
.
5. To turn off, push the power switch to the centerposition.
6. To remove the hose, twist the hose clockwise and slide
hoseoff.
Figure E
6
23
Setting the automatic shut-off pressure
NOTE: The LCD will only show inflation pressures when the
inflator is being used. In both inflation and pump mode the
unit will show batterystatus.
1. To switch between the different units (psi, bar or kPa),
press the mode toggle button
3
until the required units
aredisplayed.
2. Press the - or + pressure setting buttons
4
until the
required pressure isdisplayed.
3. After 3 seconds the display will flash and return to a
reading of "0.0". This isnormal.
4. Connect the universal valve adaptor and accessories,
if required, to the item to be inflated, making sure that
the lever of the valve adaptor is in the down position to
lock it inplace.
5. To start the inflator press the main power switch
1
on
the side of the tire symbol
22
.
6. When the item to be inflated has reached the preset
value the unit will automatically turn off. NOTE: You
may notice the actual pressure reading may drop after a
couple of seconds. This isnormal.
7. To stop the inflator at any time, press the main power
button back to the centerposition.
NOTE: If the main power switch is turned off, all settings will
be lost and will need to be reentered. This is a safety feature
to prevent the risk of items OVERINFLATING.
USING THE INFLATOR AS A PRESSURE GAUGE
Using the inflator as a pressuer guage
1. Connect the universal valve adaptor
9
to the item to
bechecked.
2. Press the main power switch
1
on the side of the tire
symbol
22
.
3. The LCD will display the item'spressure.
4. After checking, press the main power button back
to the center position and return the air hose to the
storagelocation.
MAINTENANCE
Use only a dry cloth to clean the tool. Never let any liquid
get inside the tool; never immerse any part of the tool into
aliquid.
IMPORTANT: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (other than those listed
in this manual) should be performed by authorized service
centers or other qualified service personnel, always using
identical replacementparts.
ACCESSORIES
Recommended accessories for use with your
appliance are available from your local dealer or
authorized service center. If you need assistance
regarding accessories, please call: 1-800-544-6986.

WARNING: The use of any accessory not
recommended for use with this appliance could
behazardous.
SERVICE INFORMATION
All BLACK+DECKER Service Centers are staffed
with trained personnel to provide customers with
efficient and reliable power tool service. Whether
you need technical advice, repair, or genuine factory
replacement parts, contact the
BLACK+DECKER
location nearest you. To find your local service
location, call: 1-800-544-6986 or visit
www.blackanddecker.com
