Warning! The vibration emission value
during actual use of the power tool can
dier from the declared value depending on
the ways in which the tool is used. The
vibration level may increase above the level
stated.
When assessing vibration exposure to
determine safety measures required by
2002/44/EC to protect persons regularly
using power tools in employment, an
estimation of vibration exposure should
consider, the actual conditions of use and
the way the tool is used, including taking
account of all parts of the operating cycle
such as the times when the tool is switched
o and when it is running idle in addition to
the trigger time.
Labels on tool
The following pictograms are shown on the
tool; along with the date code
Warning! To reduce the risk of injury,
the user must read the instruction
manual.
Electrical safety
Your charger is double insulated;
therefore no earth wire is required.
Always check that the mains voltage
corresponds to the voltage on the
rating plate. Never attempt to
replace the charger unit with a
regular mains plug.
• If the supply cord is damaged, it must be
replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
Features
This tool includes some or all of the
following features.
1. Variable speed switch or two-speed
on/o switch
2. Forward/reverse slider
3. Mode selector / torque adjustment collar
4. Chuck
5. Battery
6. Battery release button
fig. C & D
7. Charger
8. Charger receptacle
9. Charger connector
10. Charger plug
Assembly
Warning! Before assembly, remove the
battery from the tool.
Fitting and removing the battery (fig. A)
• To fit the battery (5), line it up with the
receptacle on the tool. Slide the battery
into the receptacle and push until the
battery snaps into place.
• To remove the battery, push the release
button (6) while at the same time pulling
the battery out of the receptacle.
Fitting the battery cap (fig. B)
Warning! Fit the cap (11) to the battery (5)
for transportation and storage.
Fitting and removing a drill bit or
screwdriver bit (fig. E)
Warning! First remove the battery from the
tool.
This tool is fitted with a keyless chuck to
allow for an easy exchange of bits.
• Lock the tool by setting the forward/
reverse slider (2) to the centre position.
• Open the chuck by turning the front part
(12) with one hand while holding the rear
part (13) with the other.
• Insert the bit shank (14) into the chuck.
• Firmly tighten the chuck by turning the
front part (12) with one hand while
holding the rear part (13) with the other.
Removing and refitting the chuck (fig. F)
• Open the chuck as far as possible.
• Remove the chuck retaining screw by
turning it clockwise using a screwdriver.
7
ENGLISH
(Original instructions)
