ENGLISH
8
(Original instructions)
• Tighten an Allen key (15) into the chuck
and strike it with a hammer as shown.
• Remove the Allen key.
• Remove the chuck by turning it
counterclockwise.
• To refit the chuck, screw it onto the
spindle and secure it with the chuck
retaining screw.
Residual risks
Additional residual risks may arise when
using the tool which may not be included in
the enclosed safety warnings. These risks
can arise from misuse, prolonged use etc.
Even with the application of the relevant
safety regulations and the implementation
of safety devices, certain residual risks can
not be avoided. These include:
• Injuries caused by touching any
rotating/moving parts.
• Injuries caused when changing any
parts, blades or accessories.
• Injuries caused by prolonged use of a
tool. When using any tool for prolonged
periods ensure you take regular breaks.
• Impairment of hearing.
• Health hazards caused by breathing
dust developed when using your tool
(example:- working with wood,
especially oak, beech and MDF.)
Use
Warning! Let the tool work at its own pace.
Do not overload.
Charging the battery
The battery needs to be charged before first
use and whenever it fails to produce
sufficient power on jobs that were easily
done before. When charging the battery for
the first time, or after prolonged storage, it
will only accept an 80% charge. After
several charge and discharge cycles, the
battery will attain full capacity. The battery
may become warm while charging; this is
normal and does not indicate a problem.
Warning! Do not charge the battery at
ambient temperatures below 10 °C or above
40 °C. Recommended charging temperature:
approx. 24 °C.
Charger with charger receptacle (fig. C)
• To charge the battery (5), remove it from
the tool and slide the charger receptacle
(8) onto the battery.
• Plug in the charger (7).
After normal use, a charging time of 3 hours
will provide sufficient power for most
applications. However, further charging for
up to 6 hours could significantly increase the
use time, depending on the battery and
charging conditions.
• Remove the battery from the charger.
Charger with charger plug (fig. D)
• To charge the battery, make sure that it is
fitted on the tool.
• Insert the charger plug (10) into the
connector (9).
• Plug in the charger (7).
• Switch on at the mains.
After normal use, a charging time of 3 hours
will provide sufficient power for most
applications. However, further charging for
up to 6 hours could significantly increase the
use time, depending on the battery and
charging conditions.
• Disconnect the tool from the charger.
Warning! Do not use the tool while it is
connected to the charger.
Selecting the direction of rotation
For drilling and for tightening screws, use
forward (clockwise) rotation. For loosening
screws or removing a jammed drill bit, use
reverse (counterclockwise) rotation.
• To select forward rotation, push the
forward/reverse slider (2) to the left.
• To select reverse rotation, push the
forward/reverse slider to the right.
• To lock the tool, set the forward/reverse
slider into the centre position.
