WARNING: When the mode selection collar is in the drill position, the drill will not clutch. The drill may stall if
overloaded, causing a sudden twist.
Symbol Mode
Drilling
1-15 Screwdriving (higher number = greater torque)
On Board Bit Storage (Fig. F)
A bit storage slot 7 is built into the base of the tool.
Performing an Application (Fig. A, E)
WARNING: To reduce the risk of personal injury, ALWAYS ensure workpiece is anchored or clamped firmly.
WARNING: Always wait until the motor has come to a complete standstill before changing the direction of rotation.
Prior to Performing Work
Install the appropriate bit or accessory into the chuck. Refer to Installing a Bit or Accessory into a Keyless
Chuck
WARNING:
Do not use this tool to mix or pump easily combustible or explosive fluids (benzine, alcohol, etc.).
Do not mix or stir flammable liquids labeled accordingly
Screwdriving
Your tool has a clutch with adjustable torque for driving and removing a wide array of fastener shapes and sizes. The
numbers 1–15 on the mode selection collar 3 are used to set a torque range for screwdriving. The higher the number
on the collar, the higher the torque and the larger the fastener which can be driven.
1. Turn the mode selection collar 3 to the desired position. Refer to Mode Selection.
2. Pull the trigger switch applying pressure in a straight line with the bit until the fastener is seated at the desired
depth in the workpiece.
Recommendations for Screwdriving
Start with lower torque settings, then advance to higher torque settings to avoid damage to the workpiece or
fastener.
Make some practice runs in scrap or on unseen areas of the workpiece to determine the proper position of the
mode selection collar.
Drilling
IMPORTANT: For MASONRY, such as brick, cement, cinder block, etc., use carbide-tipped masonry bits.
1. Turn the mode selection collar 3 to the drill symbol.
Refer to Mode Selection.
2. Place drill bit in contact with the workpiece.
NOTE: Use sharp drill bit only.
3. Pull the trigger switch applying pressure in a straight line with the bit until it reaches the desired depth.
WARNING: Drill may stall if overloaded causing a sudden twist. Always expect the stall. Grip the drill firmly to
control the twisting action and avoid injury.
4. Keep the motor running when pulling the bit back out of a drilled hole to prevent jamming.
Recommendations for Drilling
When drilling, always apply pressure in a straight line with the bit, but do not push hard enough to stall the motor
