BLADEZ Master GS - CONSOLE OPERATIONS; DISPLAY FUNCTIONS AND DATA

20
CONSOLE OPERATIONS
GENERAL:
is console has an LCD which displays; Speed, RPM, Calories, Distance, Time and
Pulse (optional).
POWER ON/OFF
e display will show all data upon pedaling. Once pedaling stops, the LCD will blink,
displaying the latest data before pedaling stopped. e display will turn o once pedaling
has stopped for over 45 seconds.
DISPLAY DATA:
A.SPEED
Located on top of the LCD display. Shows current speed with pointer.
TIME
Shows total time of the workout. Range: 00:00~99:59
B. RPM
Rotation Per Minute. Range: 0~140. If RPM exceeds 140, LCD will show STOP as a
safety reminder.
C. CALORIES
Shows calories consumed during workout. Range: 000.0~999.9.
D. DISTANCE
Range: 0~999.9; Change increment: 0.1 miles.
E. PULSE
When using a compatible wireless heart rate chest strap, the bottom of the LCD will
show heart rate (chest strap not included). Range: 60~ 240 BPM.
